Description:

    Suitable for 600 series helicopter model. The motor is manufactured to a high standard by STEAM with superb CNC turning and milling composite processing technology. The motor is equipped with an efficient active heat sink, which brings ultra-low temperature and effectively improves the energy conversion efficiency.

    Installation dimensions：25mm/30mm

Parameter:

Stator Diameter 40mm

Stator Thickness 35mm

Motor KV 1090kv

No-Load Current (lo/10v)  9.4A

Motor Resistance (RM) 5.8mΩ

Max Continuous Current 150A

Max Continuous Power 3300W

Gear Shaft length 38mm

Outside Diameter 49.6mm

Shaft Diameter 6mm

Body Length 60mm

Overall Shaft Length 98mm

Max Peak Current 171A(2 seconds)

Max peak Power 3800W(2 seconds)

Max lipo cell 6S

Weight 415g

Specification:

1050KV Brushless motor×1

M3×8mm Socket screw×4

Φ5.5 Connected head×3
